SHC-1000 Hypochlorous Acid Generator is using the self-developed non-diaphragm electrochemical technology, the safe, effective, non-toxic, non-irritating and environmentally friendly hypochlorous acid disinfection water in the range of 30-300ppm can be quickly and efficiently prepared in 1-3 seconds after starting the machine.
Machine Size: 800*380*1500mm
Water Production: 1000L/hour
Concentration PPM: 30-300ppm
PH Concentration: 5.0-6.5
ORP: >1100mv
Advantage:
* Safe:
In completely compliance with the national standards from <Hygienic requirements for disinfectants with chlorine>, <Hygienic requirements for acidic electrolyed water generator>.
* Efficient:
1) Sterilization rate 99.99%;
2) Sterilization time: within 1minute.
* Environmently Friendly:
1) The pH value is between 5-6.5, it is slightly acidic, colorless, non-irritating, non-toxic, safe, harmless and no harm to the skin;
2) It ends with water.
*Convenient and Economic:
Open and use, cleaning and disinfection two-in-one
*Multiple Functions:
Sterilization, preservation, deodorization, pesticide residue removal, biofilm removal
Scope of Application:
Livestock Disinfection:
The development direction and trend of Livestock is to use less chemical drugs to achieve green aquaculture. Complete eradication programmes are needed to control virus generation and spread. The complete elimination program is the implementation of each elimination link in place, the use of efficient, safe, non-drug resistance elimination products.
Shine hypochlorous acid generator through electrolytic HCL and aquatic production of high concentration, high stability of Enlu hypochlorite solution, pH adjustment range of 5.5-6, effective chlorine concentration of 500ppm, ORP700-900mV. This hypochlorous acid can quickly kill all kinds of viruses and pathogenic microorganisms, do not make it produce drug resistance, can be used for a long time, and the generator does not involve dangerous chemicals in the production process, safe and environmental protection; The solution naturally degrades to salt and water after sterilization, without harmful by-products, and has no stimulating effect on pigs. A generator can complete the elimination of the whole farm work, that is, at the same time used for pig house environment disinfection, in and out of personnel and vehicles disinfection, livestock and poultry drinking water sterilization, effectively cut off the transmission of bacteria, viruses, disease prevention, avoid economic losses.
Raising pig safety saves worry less investment more income:
1. The mortality rate of pigs was reduced by 80% and there is no swine fever.
2. Sow productivity increased from 80% to 90%.
3. The mortality rate during fattening was reduced from 3.5% to 1.5%.
4. Mortality at weaning decreased from 1.5%-0.8%.
Drug use in raising chicken was reduced by 90%, with no drug resistance in the whole process:
1. Egg production rate increased 2.32% year on year
2. Slaughter rate increased by 1.5% on average
3. The average weight gain of broilers is 82g
4. Feed conversion ratio is reduced by 2% on average
Raising cattle is safe, less investment and more income:
1. 87% less input for cattle
2. 92% reduction in mortality rate
3. Prevention and control of foot-and-mouth disease and mastitis
Solution
Disinfection of drinking water and breeding water of livestock and poultry:
Using Shine hypochlorite solution can quickly kill pathogenic bacteria in drinking water of livestock and poultry, remove biofilm, make the total number of bacteria in water and coliform group 0, effectively eliminate animal diseases, reduce the use of antibiotics, improve the competitiveness of enterprises, but also improve the digestive system of animals, promote drinking water, eating, reduce the ratio of feed to meat; The solution is also suitable for disinfection of aquatic products and aquaculture water, safe and non-irritating.
Disinfection of space environment:
Using Shine hypochlorite solution to disinfect the shed and surrounding environment can effectively kill pathogenic bacteria on the surface of objects and in the air to prevent infection. Can take the living body spray disinfection, does not produce any harm to livestock and poultry, at the same time the solution has a significant effect on deodorization.
Disinfection of personnel, vehicles and tools:
The Shine hypochlorite solution is used for washing hands and washing boots for the staff, and can also be used for the disinfection of vehicles and all kinds of production tools, quickly and effectively kill all kinds of pathogenic microorganisms, no irritation to the skin, no corrosion to vehicles and equipment.
Product application video
Products Parameter:
Concentration PPM | 3-500ppm |
Flow | 1000L/hour |
Available chlorine concentration | 3-500mg/L |
Power requirements | AC220V 50Hz |
Power | 1200W |
Current setting value | 0.1-2.2A |
Electrolyte | dilute HCL |
Water inlet pressure | 0.15Mpa---0.25Mpa |
Electrolyzer life | 6000 hours |
Size | 800*380*1500mm |
